产品简介

• Universal PCI interface, supports both +5 V and +3.3 V PCI bus.
• Card ID function
• Pull-high/ pull-low resistors for DI
• 16-channels digital Input
• 16-channels digital output
• 2 channels, 12-bit analog output
• 16-bit high resolution, 100 k/Ss (200 kS/s for F version) A/D converter
• 32 single-ended/16 differential analog inputs
• Programmable low gain:1/2/4/8
• Built-in 8 k WORD FIFO
• Built-in MagicScan controller
• Support internal/external trigger
• Three external triggers: post-trigger, pre-trigger, middle-trigger
